Description
By combining RED color science and Nikon engineering, the Nikon ZR Cinema Camera is a first-of-its-kind powerhouse designed to capture stunning cinematic images in one compact body. This tiny Z-mount cinema camera allows you to use a variety of lenses, and internal stabilization provides a smooth, steady image with 15+ stops of dynamic range. Features include 32-bit float audio, advanced autofocus, dual-base ISO, and up to 6K60 video capture in REDCODE, N-RAW, or ProRes RAW.
Items Included
Nikon ZR Cinema Camera
Nikon EN-EL15c Lithium-Ion Battery (2280mAh)
Nikon UC-E25 USB Cable
Nikon BS-D1 Digital Accessory Shoe Cover
Nikon BF-N1 Body Cap
Nikon AN-DC26 Camera Strap
Nikon ZR Z Mount Specs
Key Specs
| Image Sensor |
Full-Frame
|
| Effective Sensor Resolution |
24.5 Megapixel
|
| Image Stabilization |
Sensor-Shift
|
| ISO/Gain Sensitivity |
Dual Base: 800 / 6400
Native: 100 to 64,000
|
| Max Recording Modes |
ProRes RAW 12-Bit
Up to 6K at 23.98/25/29.97 fps
REDCODE RAW 12-Bit
Up to 6K at 23.98/25/29.97/50/59.94 fps
H.265 4:2:0 8/10-Bit
Up to 5.3K at 23.98/25/29.97/50/59.94 fps
ProRes 422 HQ 4:2:2 10-Bit
Up to 5.3K at 23.98/25/29.97 fps
H.264 4:2:0 8-Bit
1080p at 23.98/25/29.97/50/59.94 fps
|
| Max Video Output |
UHD 4K
|
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
Slot 2: microSD/microSDHC/microSDXC (UHS-I)
|
| Video I/O |
Micro-HDMI
|
| Mobile App Compatible |
Yes: Android & iOS
|
| Battery |
Nikon EN-EL15c
|
Imaging
| Lens Communication |
Yes: with Autofocus Support
|
| Image Sensor |
35.9 x 23.9 mm (Full-Frame) CMOS
|
| Effective Sensor Resolution |
24.5 Megapixel
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Built-In ND Filter |
No
|
| Built-In CC Filter |
No
|
| Internal Filter Holder |
No
|
| Capture Type |
Stills & Video
|
Exposure Control
| Shutter Type |
Electronic Rolling Shutter
|
| Shutter Speed |
Electronic Shutter
1/16000 to 900 Seconds
|
| Shutter Angle |
5.6 to 360°
|
| ISO/Gain Sensitivity |
Dual Base: 800 / 6400
Native: 100 to 64,000
|
| Signal-to-Noise Ratio |
Not Specified by Manufacturer
|
| Advertised Dynamic Range |
15 Stops
|
| White Balance |
Range: 2500 to 10,000K
Presets: Auto, Cloudy, Color Temperature, Direct Sunlight, Flash, Fluorescent, Incandescent, Preset Manual, Shade
|
| Exposure Modes |
Auto, Manual
|
Focus
| Focus Mode |
Automatic, Continuous-Servo AF, Full-Time Servo, Manual Focus
|
Video Capture
| Internal Recording |
ProRes RAW 12-Bit
6048 x 3402 at 23.98/25/29.97 fps
4030 x 2268 at 23.98/25/29.97/50/59.94 fps
REDCODE RAW 12-Bit
6048 x 3402 at 23.98/25/29.97/50/59.94 fps (780 to 1710 Mb/s)
4030 x 2268 at 23.98/25/29.97/50/59.94 fps (700 to 1710 Mb/s)
3984 x 2240 at 23.98/25/29.97/50/59.94/100/120 fps
H.265 4:2:0 8/10-Bit
5376 x 3024 at 23.98/25/29.97/50/59.94 fps
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200/240 fps
ProRes 422 HQ 4:2:2 10-Bit
5376 x 3024 at 23.98/25/29.97 fps
3840 x 2160 at 23.98/25/29.97/50/59.94 fps
1920 x 1080 at 50/59.94/100/120 fps
H.264 4:2:0 8-Bit
1920 x 1080 at 23.98/25/29.97/50/59.94 fps
|
| Video Output |
3840 x 2160
|
| Fast-/Slow-Motion Support |
Yes
|
| Gamma Curve |
Nikon N-Log, REDWideGamutRGB
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
ProRes, Raw: 2-Channel, 32-Bit
ProRes, Raw: 2-Channel, 24-Bit
|
| IP Streaming |
No
|
Interface
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
Slot 2: microSD/microSDHC/microSDXC (UHS-I)
|
| Internal Storage |
No
|
| Video I/O |
1x Micro-HDMI Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Mic/Line Input
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
|
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 2) Data Output (Shared with Power Input)
|
| Wireless |
Wi-Fi / Bluetooth
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: SnapBridge
|
| Global Positioning (GPS, GLONASS, etc.) |
No
|
Monitor
| Display Type |
Primary Monitor: Articulating 4″ Touchscreen LCD
|
| Resolution |
Primary Monitor: 3,070,000 Dot
|
General
| Shoe Mount |
1x Intelligent Hot Shoe
|
| Tripod Mount |
1x 1/4″-20 Female (Bottom)
|
| Accessory Mounting Thread |
No
|
| Dimensions (W x H x D) |
5.2 x 3.2 x 1.9″ / 133 x 80.5 x 48.7 mm
|
| Weight |
1.19 lb / 540 g (Body Only)
|
Packaging Info
| Package Weight |
2.27 lb
|
| Box Dimensions (LxWxH) |
8 x 7 x 5.3″
|
