Description
Pairing a powerful full-frame 24.2MP CMOS sensor and DIGIC X image processor, the R8 delivers high resolution imagery with rich and accurate colors. Designed to work in a variety of lighting condition, this camera offers a flexible ISO 100-102400 range that is expandable to ISO 204800 for working in difficult lighting conditions. Using the full width of the sensor, 6K oversampled UHD 4K 60p video recording is supported as is Full HD 1080 180p for slow motion playback. The R8 offers 4:2:2 10-bit shooting and up to 2-hours of video recording is now available at 29.97 fps, allowing you to keep your project rolling. Capable of processing high speed bursts, the DIGIC X image processor also supports up to 40 fps continuous shooting and offers pre-shooting support, which allows the camera to start recording images 0.5 seconds prior to pressing the shutter release button.
Key Specs
| Lens Mount |
Canon RF
|
| Sensor Resolution |
Actual: 25.6 Megapixel
Effective: 24.2 Megapixel
|
| Image Sensor |
35.9 x 23.9 mm (Full-Frame) CMOS
|
| Image Stabilization |
Digital, 5-Axis (Video Only)
|
| ISO Sensitivity Range |
Photo/Video
100 to 102,400 (Extended: 50 to 204,800)
|
| Continuous Shooting |
Electronic Shutter
Up to 40 fps for up to 120 Frames (JPEG) / 56 Frames (Raw)
|
| Internal Recording Modes |
H.264/H.265/MP4 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps [340 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/150/180 fps [270 Mb/s]
|
| External Recording Modes |
HDMI
1920 x 1080p at 50/59.94 fps
|
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI (Unspecified Signal) Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input on Camera Body
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output on Camera Body
|
| Power I/O |
1x USB-C Input/Output
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 2) (Shared with Power Input)
|
| Wireless |
2.4 / 5 GHz Wi-Fi 4 (802.11n), Bluetooth 4.2 Control
|
| Display Type |
Articulating Touchscreen LCD
|
| Battery Type |
1x LP-E17 Rechargeable Lithium Polymer (Approx. 150 Shots)
|
Imaging
| Lens Mount |
Canon RF
|
| Sensor Resolution |
Actual: 25.6 Megapixel
Effective: 24.2 Megapixel
|
| Image Sensor |
35.9 x 23.9 mm (Full-Frame) CMOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1x
Additional Modes: 1.6x
*Additional Crop Occurs in Select Video Modes
|
| Image Stabilization |
Digital, 5-Axis (Video Only)
|
| Built-In ND Filter |
No
|
| Capture Type |
Stills & Video
|
Exposure Control
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Electronic Shutter
1/8000 Up to 30 Second
1/16000 Up to 30 Seconds in Manual Mode
1/16000 Up to 30 Seconds in Shutter Priority Mode
Electronic Front Curtain Shutter
1/4000 Up to 30 Seconds
|
| Bulb/Time Mode |
Bulb Mode
|
| ISO Sensitivity Range |
Photo/Video
100 to 102,400 (Extended: 50 to 204,800)
|
| Metering Method |
Center-Weighted Average, Evaluative, Partial, Spot
|
| Precise Scan Rate Control |
Yes
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Metering Range |
-3 to 20 EV
|
| White Balance |
2500 to 10,000K
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Kelvin, Shade, Tungsten
|
| Continuous Shooting |
Electronic Shutter
Up to 40 fps for up to 120 Frames (JPEG) / 56 Frames (Raw)
|
| Interval Recording |
Yes
|
| Self-Timer |
2/10-Second Delay
|
Still Image Capture
| Image Sizes |
3:2 Raw
24 MP (6000 x 4000)
3:2 JPEG
24 MP (6000 x 4000)
10.6 MP (3984 x 2656)
5.9 MP (2976 x 1984)
3.8 MP (2400 x 1600)
1:1 JPEG
16 MP (4000 x 4000)
7.1 MP (2656 x 2656)
3.9 MP (1984 x 1984)
2.6 MP (1600 x 1600)
4:3 JPEG
21.3 MP (5328 x 4000)
9.5 MP (3552 x 2664)
5.3 MP (2656 x 1992)
3.4 MP (2112 x 1600)
16:9 JPEG
20.2 MP (6000 x 3368)
8.9 MP (3984 x 2240)
5 MP (2976 x 1680)
3.2 MP (2400 x 1344)
|
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
| Image File Format |
C-RAW, HEIF, JPEG, Raw
|
Video Capture
| Internal Recording Modes |
H.264/H.265/MP4 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps [340 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/150/180 fps [270 Mb/s]
|
| External Recording Modes |
HDMI
1920 x 1080p at 50/59.94 fps
|
| Fast-/Slow-Motion Support |
Yes
|
| Gamma Curve |
Canon Log 3, HDR-PQ
|
| Recording Limit |
Up to 120 Minutes in 4K
Up to 120 Minutes in 1080p HFR
|
| Broadcast Output |
NTSC/PAL
|
| IP Streaming |
No
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
AAC Audio
LPCM Audio
|
Interface
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI (Unspecified Signal) Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input on Camera Body
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output on Camera Body
|
| Power I/O |
1x USB-C Input/Output
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 2) (Shared with Power Input)
|
| Wireless |
2.4 / 5 GHz Wi-Fi 4 (802.11n), Bluetooth 4.2 Control
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed
|
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone
|
Monitor
| Display Size |
3″
|
| Resolution |
1,620,000 Dot
|
| Display Type |
Articulating Touchscreen LCD
|
Viewfinder
| Type |
Built-In Electronic (OLED)
|
| Size |
0.39″
|
| Resolution |
2,360,000 Dot
|
| Eye Point |
22 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 70x
|
| Diopter Adjustment |
-4 to +1
|
Focus
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF
|
| Autofocus Points |
Phase Detection: 4897
Video
Phase Detection: 4067
|
| Autofocus Sensitivity |
-6.5 to +21 EV
|
Flash
| Built-In Flash/Light |
No
|
| Flash Modes |
Auto
|
| Maximum Sync Speed |
1/200 Second
|
| Flash Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Dedicated Flash System |
eTTL
|
| External Flash Connection |
Shoe Mount
|
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Operating Humidity |
0 to 85%
|
General
| Battery Type |
1x LP-E17 Rechargeable Lithium Polymer (Approx. 150 Shots)
|
| Shoe Mount |
1x Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4″-20 Female (Bottom)
|
| Dimensions (W x H x D) |
5.22 x 3.39 x 2.76″ / 132.59 x 86.11 x 70.1 mm
|
| Weight |
1.0 lb / 461 g (With Battery, Recording Media)
0.9 lb / 414 g (Body Only)
|
