For the professional image-maker who needs resolution, speed, and video capabilities, the
Canon EOS R5 full-frame mirrorless camera features a newly developed 45MP CMOS sensor, which offers 8K raw video recording, 12 fps continuous shooting with a mechanical shutter, and is the first EOS camera to feature 5-axis sensor-shift image stabilization.
Built around a newly developed 45MP full-frame CMOS sensor, the EOS R5 offers both high-resolution stills and video output and the fine-tuned DIGIC X image processor complements this with a wealth of speed. Sensitivity from ISO 100-51200, which can be expanded to ISO 102400, suits working in a variety of lighting conditions while quick continuous shooting up to 12 fps with a mechanical shutter, or silent 20 fps with an electronic shutter, is ideal for working with moving subjects.
Key Specs
| Lens Mount |
Canon RF
|
| Sensor Resolution |
Actual: 47.1 Megapixel
Effective: 45 Megapixel (8192 x 5464)
|
| Image Sensor |
36 x 24 mm (Full-Frame) CMOS
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| ISO Sensitivity Range |
100 to 51,200 (Extended: 50 to 102,400)
Video
100 to 25,600 (Extended: 51,200)
|
| Internal Recording Modes |
Raw 12-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [2600 Mb/s]
H.264 4:2:0 8-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [470 to 1300 Mb/s]
UHD 8K (7680 x 4320) at 23.98/25/29.97 fps [470 to 1300 Mb/s]
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94/100/120 fps [120 to 1880 Mb/s]
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100 fps [120 to 1880 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [12 to 180 Mb/s]
H.265 4:2:2 10-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [680 to 1300 Mb/s]
UHD 8K (7680 x 4320) at 23.98/25/29.97 fps [680 to 1300 Mb/s]
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/59.94/100/120 fps [170 to 1880 Mb/s]
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100 fps [170 to 1880 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [28 to 230 Mb/s]
|
| External Recording Modes |
4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) up to 59.94 fps
UHD 4K (3840 x 2160) up to 59.94 fps
ProResRAW 10-Bit via HDMI
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps
5088 x 2680 at 23.98/24.00/25/29.97/50/59.94 fps
|
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
|
| Video I/O |
1x Micro-HDMI Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
|
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 2) Data Output (Shared with Power Input)
1x Canon N3 Remote Input
|
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0 Control
|
| Display Type |
Free-Angle Tilting Touchscreen LCD
|
| Battery Type |
1x LP-E6NH Rechargeable Lithium-Ion
|
Imaging
| Lens Mount |
Canon RF
|
| Sensor Resolution |
Actual: 47.1 Megapixel
Effective: 45 Megapixel (8192 x 5464)
|
| Image Sensor |
36 x 24 mm (Full-Frame) CMOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1x
Additional Modes: 1.6x
*Additional Crop Occurs in Select Video Modes
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Built-In ND Filter |
No
|
| Capture Type |
Stills & Video
|
Exposure Control
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Mechanical Shutter
1/8000 to 30 Seconds
Electronic Front Curtain Shutter
1/8000 to 30 Seconds
Electronic Shutter
1/8000 to 1/2 Second
|
| Bulb/Time Mode |
Bulb Mode
|
| ISO Sensitivity Range |
100 to 51,200 (Extended: 50 to 102,400)
Video
100 to 25,600 (Extended: 51,200)
|
| Metering Method |
Center-Weighted Average, Evaluative, Partial, Spot
|
| Exposure Modes |
Aperture Priority, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Metering Range |
-3 to 20 EV
|
| White Balance |
2000 to 10,000K
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
|
| Continuous Shooting |
Up to 20 fps at Maximum Resolution for up to 83 Frames (Raw) / 170 Frames (JPEG)
|
| Interval Recording |
Yes
|
| Self-Timer |
2/10-Second Delay
|
Still Image Capture
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
| Image File Format |
JPEG, Raw
|
| Bit Depth |
14-Bit
|
Video Capture
| Internal Recording Modes |
Raw 12-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [2600 Mb/s]
H.264 4:2:0 8-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [470 to 1300 Mb/s]
UHD 8K (7680 x 4320) at 23.98/25/29.97 fps [470 to 1300 Mb/s]
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94/100/120 fps [120 to 1880 Mb/s]
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100 fps [120 to 1880 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [12 to 180 Mb/s]
H.265 4:2:2 10-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [680 to 1300 Mb/s]
UHD 8K (7680 x 4320) at 23.98/25/29.97 fps [680 to 1300 Mb/s]
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/59.94/100/120 fps [170 to 1880 Mb/s]
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100 fps [170 to 1880 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [28 to 230 Mb/s]
|
| External Recording Modes |
4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) up to 59.94 fps
UHD 4K (3840 x 2160) up to 59.94 fps
ProResRAW 10-Bit via HDMI
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps
5088 x 2680 at 23.98/24.00/25/29.97/50/59.94 fps
|
| Fast-/Slow-Motion Support |
Yes
|
| Gamma Curve |
Canon Log, Canon Log 3
|
| Recording Limit |
Up to 30 Minutes
|
| IP Streaming |
Yes
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
AAC Audio
LPCM Audio
|
Interface
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
|
| Video I/O |
1x Micro-HDMI Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
|
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 2) Data Output (Shared with Power Input)
1x Canon N3 Remote Input
|
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0 Control
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed
|
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone
|
Monitor
| Display Size |
3.2″
|
| Resolution |
2,100,000 Dot
|
| Display Type |
Free-Angle Tilting Touchscreen LCD
|
| Secondary Display |
Top: Status Display
|
Viewfinder
| Type |
Built-In Electronic (OLED)
|
| Size |
0.5″
|
| Resolution |
5,760,000 Dot
|
| Eye Point |
23 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 0.76x
|
| Diopter Adjustment |
-4 to +2
|
Focus
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF
|
| Autofocus Points |
Phase Detection: 1053
|
| Autofocus Sensitivity |
-6 to +20 EV
|
Flash
| Built-In Flash/Light |
No
|
| Maximum Sync Speed |
1/250 Second
|
| Flash Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Dedicated Flash System |
eTTL
|
| External Flash Connection |
PC Terminal
|
General
| Battery Type |
1x LP-E6NH Rechargeable Lithium-Ion
|
| Shoe Mount |
1x Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4″-20 Female (Bottom)
|
| Material of Construction |
Magnesium Alloy
|
| Operating Conditions |
32 to 104°F / 0 to 40°C up to 85% Humidity
|
| Dimensions (W x H x D) |
5.43 x 3.84 x 3.46″ / 138 x 97.5 x 88 mm
|
| Weight |
1.4 lb / 650 g (Body Only)
1.6 lb / 738 g (With Battery, Recording Media)
|
