Description
The Sony a6700’s advanced imaging system is powered by the 26MP APS-C Exmor R CMOS sensor and BIONZ XR processor, a combination introduced in the FX30 Digital Cinema Camera that is capable of 10-bit UHD 4K imagery at up to 120 fps or a top continuous shooting rate of 11 fps with AF and AE and up to 59 compressed raw still images in bursts. The introduction of the back-illuminated structure to the camera’s sensor gives it a higher resolution without sacrificing sensitivity. With an ISO range of 100-32000 that’s expandable to ISO50-102400 when shooting stills, the camera boasts low-light performance with minimal noise and more than 14 stops of dynamic range.
Key Specs
| Lens Mount |
Sony E
|
| Sensor Resolution |
Actual: 27 Megapixel
Effective: 26 Megapixel (6192 x 4128)
|
| Image Sensor |
23.3 x 15.5 mm (APS-C) CMOS
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| ISO Sensitivity Range |
100 to 32,000 in Manual Mode (Extended: 50 to 102,400)
100 to 6400 in Auto Mode
Video
100 to 32,000 in Manual Mode
100 to 6400 in Auto Mode
|
| Continuous Shooting |
Up to 11 fps at 26 MP for up to 59 Frames (Raw) / 1000 Frames (JPEG)
|
| Internal Recording Modes |
XAVC HS 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/50/59.94/100/120 fps [50 to 280 Mb/s]
XAVC HS 4:2:0 10-Bit
UHD 4K (3840 x 2160) at 23.98/50/59.94/100/120 fps [30 to 200 Mb/s]
XAVC S 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100/120 fps [100 to 280 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94 fps [50 Mb/s]
XAVC S 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100/120 fps [60 to 200 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120 fps [16 to 100 Mb/s]
XAVC S-I 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps [240 to 600 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94 fps [89 to 222 Mb/s]
|
| External Recording Modes |
4:2:2 10-Bit via HDMI
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps
HD (1920 x 1080) at 23.98/50/59.94 fps
|
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI (Unspecified Signal) Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input
|
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C Data Output (Shared with Power Input)
|
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2
|
| Display Type |
Articulating Touchscreen LCD
|
| Battery Type |
1x NP-FZ100 Rechargeable Lithium-Ion (Approx. 550 Shots)
|
Imaging
| Lens Mount |
Sony E
|
| Sensor Resolution |
Actual: 27 Megapixel
Effective: 26 Megapixel (6192 x 4128)
|
| Image Sensor |
23.3 x 15.5 mm (APS-C) CMOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1.5x
Additional Modes: 1.6x
*Additional Crop Occurs in Select Video Modes
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Built-In ND Filter |
No
|
| Capture Type |
Stills & Video
|
Exposure Control
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Mechanical Shutter
1/4000 to 30 Seconds
Electronic Shutter
1/8000 to 30 Seconds
|
| Bulb/Time Mode |
Bulb Mode
|
| ISO Sensitivity Range |
100 to 32,000 in Manual Mode (Extended: 50 to 102,400)
100 to 6400 in Auto Mode
Video
100 to 32,000 in Manual Mode
100 to 6400 in Auto Mode
|
| Metering Method |
Center-Weighted Average, Multi-Zone, Spot
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-5 to +5 EV (1/3, 1/2 EV Steps)
|
| Metering Range |
-3 to 20 EV
|
| White Balance |
2500 to 9900K
Presets: ATW, AWB, Auto, Cloudy, Color Temperature, Color Temperature Filter, Custom, Daylight, Flash, Fluorescent (Cool White), Fluorescent (Day White), Fluorescent (Daylight), Fluorescent (Warm White), Incandescent, Shade, Underwater
|
| Continuous Shooting |
Up to 11 fps at 26 MP for up to 59 Frames (Raw) / 1000 Frames (JPEG)
|
| Interval Recording |
Yes
|
| Self-Timer |
2/5/10-Second Delay
|
Still Image Capture
| Image Sizes |
3:2 Raw
26 MP (6192 x 4128)
4:3 Raw
23 MP (5504 x 4128)
16:9 Raw
22 MP (6192 x 3480)
1:1 Raw
17 MP (4128 x 4128)
3:2 JPEG
26 MP (6192 x 4128)
13 MP (4384 x 2920)
6.4 MP (3104 x 2064)
4:3 JPEG
23 MP (5504 x 4128)
11 MP (3888 x 2920)
5.7 MP (2752 x 2064)
16:9 JPEG
22 MP (6192 x 3480)
11 MP (4384 x 2464)
5.4 MP (3104 x 1744)
1:1 JPEG
17 MP (4128 x 4128)
8.5 MP (2912 x 2912)
4.3 MP (2064 x 2064)
|
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
| Image File Format |
HEIF, JPEG, Raw
|
| Bit Depth |
14-Bit
|
Video Capture
| Internal Recording Modes |
XAVC HS 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/50/59.94/100/120 fps [50 to 280 Mb/s]
XAVC HS 4:2:0 10-Bit
UHD 4K (3840 x 2160) at 23.98/50/59.94/100/120 fps [30 to 200 Mb/s]
XAVC S 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100/120 fps [100 to 280 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94 fps [50 Mb/s]
XAVC S 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100/120 fps [60 to 200 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120 fps [16 to 100 Mb/s]
XAVC S-I 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps [240 to 600 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94 fps [89 to 222 Mb/s]
|
| External Recording Modes |
4:2:2 10-Bit via HDMI
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps
HD (1920 x 1080) at 23.98/50/59.94 fps
|
| Fast-/Slow-Motion Support |
Yes
|
| Gamma Curve |
HDR-HLG, S Cinetone, Sony S-Log 3
|
| Recording Limit |
No
|
| IP Streaming |
No
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
XAVC: 2-Channel 16-Bit 48 kHz LPCM Audio
|
Interface
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI (Unspecified Signal) Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input
|
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C Data Output (Shared with Power Input)
|
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: Creators’ App
Functionality: Access Stored Files, Remote Control
|
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone
|
Monitor
| Display Size |
3.0″
|
| Resolution |
1,030,000 Dot
|
| Display Type |
Articulating Touchscreen LCD
|
Viewfinder
| Type |
Built-In Electronic (OLED)
|
| Size |
0.39″
|
| Resolution |
2,359,296 Dot
|
| Eye Point |
22 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 1.07x
|
| Diopter Adjustment |
-4 to +3
|
Focus
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Automatic, Continuous-Servo AF, Direct Manual Focus, Manual Focus, Single-Servo AF
|
| Autofocus Points |
Phase Detection: 759
Video
Phase Detection: 495
|
| Autofocus Sensitivity |
-3 to +20 EV
|
Flash
| Built-In Flash/Light |
No
|
| Maximum Sync Speed |
1/160 Second
|
| Flash Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Dedicated Flash System |
TTL
|
| External Flash Connection |
Shoe Mount, Wireless
|
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 131°F / -20 to 55°C
|
General
| Battery Type |
1x NP-FZ100 Rechargeable Lithium-Ion (Approx. 550 Shots)
|
| Shoe Mount |
1x Intelligent Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4″-20 Female (Bottom)
|
| Material of Construction |
Magnesium Alloy
|
| Dimensions (W x H x D) |
4.8 x 2.7 x 3″ / 122 x 69 x 75.1 mm
|
| Weight |
1.1 lb / 493 g (With Battery, Recording Media)
0.9 lb / 411 g (Body Only)
|
